DW238CP
1 / 17
Specifications
Full specifications for procurement.
Copy the structured specifications into your request for quotation or bill of materials.
Specifications come from the current approved factory specification. Values for request-only sizes are not inferred from neighbouring models. product data policy.
Specifications · 14 rows
- Screen size
- 23.8"
- Resolution
- 1920×1080
- Brightness
- 500 cd/m²
- Contrast
- 1000:1
- CPU
- Quad-core Cortex-A
- RAM
- 1 GB (2/4 GB optional)
- Internal storage
- 8 GB (16/32/64 GB optional)
- Operating system
- Android 5.0+
- Touch
- (no-touch tabletop display)
- Protection
- IP43
- Working temperature
- 0–50 °C
- Power consumption
- ≤35 W
- Body size
- 557 × 333 × 50 mm
- Certifications
- CE · FCC · RoHS
Common questions
Frequently asked and clearly answered.
Answers about suitability, customisation, lead time and warranty for this model.
Q.01What size is the Wintouch DW238CP touch screen?
The DW238CP is a 23.8 inch (23.8-inch diagonal) touch screen menu board and QSR digital menu display with a native 1920×1080 panel and 500 cd/m² brightness rating.Q.02Is the DW238CP suitable for qsr counter-service digital menu?
Yes. The 23.8 inch touch screen menu board is engineered for qsr counter-service digital menu, cafe and bakery ordering kiosk, dine-in tabletop touch menu, bar drink and cocktail menu deployments. The DW238CP is a 23.8" tabletop FHD digital menu board on Android 5.0+ with B/S browser-based control backend — used in dine-in restaurants and quick-service-restaurant counters for menu, promos and table-side ordering.Q.03What touch technology and operating system does the DW238CP use?
(no-touch tabletop display) touch with Android 5.0+ on the Quad-core Cortex-A platform, typical for cafe and bakery ordering kiosk where reliability and multi-touch responsiveness matter.Q.04Does the DW238CP support OEM customisation, custom logo, firmware and enclosure?
Yes. Wintouch offers complete OEM / ODM on the DW238CP: silk-printed or laser-engraved logo, custom enclosure CMF, branded boot animation, custom PCB I/O, custom Android / Linux / Windows OS image, and full-colour retail packaging. Samples and production orders start at 1 unit.Q.05What is the minimum order quantity, warranty and lead time for the DW238CP?
Minimum order quantity is 1 unit. Typical production lead time is 15-25 days, with samples available in 7 days. The DW238CP ships with a 12 months standard warranty, FOB Dongguan or door-to-door. A specification engineer responds within one business day.
