Retail promotion or menu content
Start with: Non-touch commercial display with remote CMS and timed power control.
Verify: Viewing distance, glare, network recovery and cleaning access.
Wall-mounted Digital Signage
Wall-mounted Digital Signage
18.5"–75" wall mounted touch screen display panels
Aluminium-profile wall mount touch screen digital signage on Rockchip RK3566 / Android 11 / Debian 11, 300 nits default (500/700/1000 optional), horizontal/vertical/split screen, customised play and power on-off, full seamless switching. 3 mm tempered glass, IP43.
Request a quote1 models, grouped by product form
- Sizes
- 18.5"-75"
- Resolution
- HD to 4K
- Platform
- RK3566 / Android 11
- Touch
- 10-point PCAP optional
- Protection
- IP43
- Operation
- 24/7 commercial
Models in this line
1 models available.
10 sizes
Buyer specification guide
How to specify Wall-mounted Digital Signage.
Use deployment conditions and integration requirements to narrow the product line before comparing unit price.
Choose wall-mounted digital signage by viewing distance, orientation and service access first, then match brightness, media platform and optional touch. A production drawing should confirm the wall structure, VESA pattern, connector clearance and cable path before the display is ordered.
Current comparison points: Sizes: 18.5"-75"; Resolution: HD to 4K; Platform: RK3566 / Android 11; Touch: 10-point PCAP optional. Validate the shortlisted configuration with the actual content, mounting method and ambient conditions before volume production.
How should a buyer specify Wall-mounted Digital Signage?
Choose wall-mounted digital signage by viewing distance, orientation and service access first, then match brightness, media platform and optional touch. A production drawing should confirm the wall structure, VESA pattern, connector clearance and cable path before the display is ordered. The current line should be compared on Sizes: 18.5"-75"; Resolution: HD to 4K; Platform: RK3566 / Android 11; Touch: 10-point PCAP optional.
Which Wall-mounted Digital Signage sizes are available?
The current Wall-mounted Digital Signage line covers 18.5"-75". Confirm the exact active area, outer dimensions and mounting drawing for the selected model before ordering.
Can Wintouch customise Wall-mounted Digital Signage for an OEM project?
Yes. Wintouch can review enclosure, logo, colour, I/O, firmware, touch, brightness, packaging and certification requirements. A production-equivalent sample should be approved before volume manufacture.
Procurement checklist
Turn the site conditions into a shortlist.
Choose wall-mounted digital signage by viewing distance, orientation and service access first, then match brightness, media platform and optional touch. A production drawing should confirm the wall structure, VESA pattern, connector clearance and cable path before the display is ordered.
DecisionRecommended starting pointWhy it matters
Screen and orientation
Size typography for the farthest viewer and lock portrait or landscape content templates.
A larger panel does not improve communication when the layout or mounting height makes content hard to scan.
Mounting and service
Confirm wall load, VESA pattern, ventilation gap and front/side service clearance.
Commercial displays need safe support and a practical replacement path throughout the installation lifetime.
Playback platform
Use RK3566 for standard CMS playback; define Windows or higher compute only when the application requires it.
Over-specifying compute raises cost and heat without improving ordinary signage playback.
Touch decision
Add PCAP only where the user can comfortably reach the screen and the application has an interaction flow.
Unused touch adds glass, controller and support complexity to an otherwise simple signage endpoint.
Match the configuration to the deployment.
Wayfinding or product finder
Start with: PCAP touch display at an accessible mounting height.
Verify: Reach range, UI target sizes and route to the power/data enclosure.
Corporate lobby or dashboard
Start with: Landscape 4K display with 24/7-capable configuration.
Verify: Content resolution, source failover and wall service clearance.
