FS SERIES
1 / 10
Specifications
Compare every size in one view.
Shared platform specifications cover the product line. Size-specific display area, dimensions and weight are listed separately.
| Specification | 32"FS320DS | 43"FS430DS | 50"FS500DS | 55"FS550DS | 65"FS650DS |
|---|---|---|---|---|---|
| Model | FS320DS | FS430DS | FS500DS | FS550DS | FS650DS |
| Screen size | 32" | 43" | 50" | 55" | 65" |
| Resolution | 1920×1080All sizes | ||||
| Brightness | 300 cd/m²All sizes | ||||
| Brightness options | 500 / 700 / 1000 cd/m² optionalAll sizes | ||||
| Contrast | 1200:1All sizes | ||||
| CPU | Rockchip RK3566 Quad Core 64-bit Cortex-A55All sizes | ||||
| RAM | 2 GB (4 GB optional)All sizes | ||||
| Internal storage | 32 GB (64 GB optional)All sizes | ||||
| Operating system | Android 11 / Debian 11All sizes | ||||
| Touch | 10-point capacitive touch (optional)All sizes | ||||
| Protection | IP43All sizes | ||||
| Working temperature | 0-50 °CAll sizes | ||||
| Body size | 1550 × 440.4 × 79 mm | 1700 × 580 × 80 mm | 1820 × 700 × 85 mm | 1900 × 770 × 85 mm | 2000 × 900 × 90 mm |
| Net weight | 25 kg | 38 kg | 52 kg | 65 kg | 82 kg |
| Power consumption | ≤ 40 W | ≤ 65 W | ≤ 95 W | ≤ 120 W | ≤ 160 W |
| Certifications | CE, FCC, RoHSAll sizes | ||||
| MOQ | 1 unit, sample availableAll sizes | ||||
| Lead time | 7 days sample, 15-25 days productionAll sizes | ||||
| Warranty | 12 months (extendable)All sizes | ||||
Specifications come from the current approved factory specification. Values for request-only sizes are not inferred from neighbouring models. product data policy.
In detail
Product features and use cases.
Cloud CMS, display performance, optional touch, hardware and installation examples for the complete FS Series.
Common questions
Frequently asked and clearly answered.
Answers about suitability, customisation, lead time and warranty for this model.
Q.01What size is the Wintouch FS320DS touch screen?
The FS320DS is a 32 inch (32-inch diagonal) floor standing touch screen kiosk with a native 1920×1080 (3840×2160 optional) panel and 300 cd/m² (500/700/1000 optional) brightness rating.Q.02Is the FS320DS suitable for shopping-mall wayfinding kiosk?
Yes. The 32 inch touch screen kiosk is engineered for shopping-mall wayfinding kiosk, hotel concierge self-service kiosk, museum interactive guide, public-service queue management terminal deployments. The FS320DS is a 32" portrait floor-standing kiosk on RK3566 / Android 11 — common in retail, banking, and lobby information stands.Q.03What touch technology and operating system does the FS320DS use?
10-point capacitive touch (optional) touch with Android 11 / Debian 11 on the Rockchip RK3566 Quad Core 64-bit Cortex-A55 platform, typical for hotel concierge self-service kiosk where reliability and multi-touch responsiveness matter.Q.04Does the FS320DS support OEM customisation, custom logo, firmware and enclosure?
Yes. Wintouch offers complete OEM / ODM on the FS320DS: silk-printed or laser-engraved logo, custom enclosure CMF, branded boot animation, custom PCB I/O, custom Android / Linux / Windows OS image, and full-colour retail packaging. Samples and production orders start at 1 unit.Q.05What is the minimum order quantity, warranty and lead time for the FS320DS?
Minimum order quantity is 1 unit. Typical production lead time is 15-25 days, with samples available in 7 days. The FS320DS ships with a 12 months standard warranty, FOB Dongguan or door-to-door. A specification engineer responds within one business day.
