WT104B24
1 / 5
Specifications
Full specifications for procurement.
Copy the structured specifications into your request for quotation or bill of materials.
Specifications come from the current approved factory specification. Values for request-only sizes are not inferred from neighbouring models. product data policy.
Specifications · 8 rows
- Screen size
- 10.4"
- Resolution
- 1024×768
- Brightness
- 350 cd/m² (500/1000 cd/m² optional)
- Contrast
- 800:1
- Touch
- 10-point projected-capacitive touch
- Protection
- IP65 (front panel)
- Working temperature
- -10 to 65 °C
- Certifications
- CE · FCC · CB · RoHS
In detail
Industrial display features and applications.
IP65 front protection, high brightness, 10-point touch, mounting options and operating environments for the complete industrial monitor line.
Common questions
Frequently asked and clearly answered.
Answers about suitability, customisation, lead time and warranty for this model.
Q.01What size is the Wintouch WT104B24 touch screen?
The WT104B24 is a 10.4 inch (10.4-inch diagonal) open-frame industrial touch monitor with HDMI and VGA with a native 1024×768 panel and 350 cd/m² (500/1000 cd/m² optional) brightness rating.Q.02Is the WT104B24 suitable for machinery hmi / equipment control monitor?
Yes. The 10.4 inch industrial touch monitor is engineered for machinery hmi / equipment control monitor, kiosk and self-service terminal display, medical and laboratory instrument monitor, oem embedded open-frame integration deployments. The WT104B24 is a 10.4" IP65 high-brightness industrial touch monitor (1024×768, 10-point PCAP) with an all-in-one HDMI / VGA + USB-touch cable, 8-36V wide-voltage input and VESA 75 mounting — a rugged, water- and dust-proof display for industrial, outdoor and self-service integration.Q.03What touch technology and operating system does the WT104B24 use?
10-point projected-capacitive touch touch with on the platform, typical for kiosk and self-service terminal display where reliability and multi-touch responsiveness matter.Q.04Does the WT104B24 support OEM customisation, custom logo, firmware and enclosure?
Yes. Wintouch offers complete OEM / ODM on the WT104B24: silk-printed or laser-engraved logo, custom enclosure CMF, branded boot animation, custom PCB I/O, custom Android / Linux / Windows OS image, and full-colour retail packaging. Samples and production orders start at 1 unit.Q.05What is the minimum order quantity, warranty and lead time for the WT104B24?
Minimum order quantity is 1 unit. Typical production lead time is 15-25 days, with samples available in 7 days. The WT104B24 ships with a 12 months standard warranty, FOB Dongguan or door-to-door. A specification engineer responds within one business day.
